China Wire Rope Sling manufacturer

Type 316 Stainless Steel Security Cable , Aircraft Wire Rope DIN Standard

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: CE / ISO 9001 : 2008
Model Number: 1x7SAC
Payment & Shipping Terms:
Minimum Order Quantity: 1MTRS
Price: USD1600/TON
Packaging Details: Plastic Reels
Delivery Time: 15 days after the order confirmation
Payment Terms: L/C, T/T
Supply Ability: 100TONS monthly

Detail Information

Alloy Or Not:Non-alloyHS Code:73121000
Construction:1 X 7Finish:Stainless
Diameter:1/16"Standard:ASTM, BS, DIN, GB, JIS
Length:500 FtSteel Grade:Carbon Steel
High Light:

aircraft wire cable

,

aircraft wire rope

Product Description



1x7 Preformed Aircraft Wire Cable Stainless Steel Type 316 High performance



To order stainless steel aircraft cable, you are requested to give us complete information as specified below:

1.Purpose: For which rope will be used.
2.Size: Diameter of the rope in millimeter or inches
3.Construction: Number of strands, number of wires per strand and type of strand construction.
4.Coating: Bright/Black(ungalvanized), galvanized or stainless, PVC or Grease.
5.Length: Length of wire rope one coil or reel
6.Lay: Right regular lay, left regular lay, right lang lay, left lang lay.
7.Packing: In coils wrapped with oil paper and hessian(orp.p) cloth, or on wooden reels.or with pallet.
8.Grade of wire: Tensile strength of wires.
9.Lubrication: Whether lubrication is desired or not, and required lubricant,A1,A2,A3
10.Breaking Load: Minimum or calculated breaking load in tones or pounds
11.Remarks: Shipping marks and any other special requirement.







LKS manufactures and stocks aircraft cable to commercial and military specifications in stainless steel, galvanized carbon steel, and a variety of other alloys. We manufacture cables to the specifications of numerous aerospace and commercial OEM's. Loos and Company is a fully integrated manufacturer: drawing wire, stranding cable, extruding jacketing material and providing custom products, configurations and processes when you require them.





Aircraft Cable

The table below represents standard materials, constructions, and sizes that we offer. As a manufacturer, we are fully capable of making custom products. If you don't see what you are looking for here, please contact a sales representative and we will get back to you shortly.




Stainless Steel 302/304 305 316 Galvanized Specialty Alloys
1x7 - 1x7 1x7 -
1x19 - 1x19 1x19 -
3x7 - - 3x7 -
7x7 7x7 7x7 7x7 7x7
7x19 7x19 7x19 7x19 7x19
19x7 - - - -



Specification



Diameter Specification Min. Breaking Strength Approx. Weight Per 100'
7/32 Commercial 5,700 10.6
1/4 Commercial 7,650 13.7
9/32 Commercial 9,650 17.6
5/16 Commercial 11,900 20.5
3/8 Commercial 16,200 30
7/16 Commercial 23,400 45
1/2 Commercial 30,200 56



Trade Terms



Trade Terms EXW, FOB, CIF or Others
MOQ 1 Ton
FOB Price 1550-2666USD/Ton
Port SHANGHAI,China or Others
Shipment By Sea, By Air
Payment Terms T/T, L/C or Others
Payment Condition 30% Before Production, 70% before delivery
Supply Capability 300Tons/month
Sample Availability Yes
Sample Time 3-7days
Packing

Soft Coil, Poly Bag, Woven Bag, Carton,Plastic Spool,

Wooden Spool, Wooden Case, Wooden Pallet,etc.

Delivery Time 25-30 days after confirmation
Service OEM or Customized



Our Services



We really hope that you would find your demand in our site. Our QUALITY & SERVICE will win your hearts.
