LKS-K9 Port Crane Steel Wire Rope Excellent wear resistance for port loading/unloading

Product Description

The working environment of the steel wire rope of the port crane belongs to the frequent lifting equipment. Therefore, the fatigue resistance of the wire rope of the port crane is higher. In most cases, we mainly line contact wire rope, such as the common 6 x 36WS+IWR and 6 x 31WS+IWR, and the wire rope specifications are also concentrated in the 26mm-52mm. With the economic development, the demand for the port crane steel rope is increasing, and the demand for the quality is getting higher and higher. The steel wire manufacturers continue to invest in the research force and update the production equipment. The steel wire rope in the port is gradually developed from the previous 6 wire contact to the steel wire, and the number of the wire rope has started to increase. More, 8 x 36WS+IWR and 8 x 31WS+IWR gradually replace 6 strands, because 8 strand wire rope has softer performance and fatigue resistance.

During the operation of the steel wire rope of the port crane, the continuous wear and loss between steel wire and steel wire is easy to appear in the early stage, so in many cases, as a manufacturer of wire rope, first of all, it is necessary to improve the oil coating method of the wire rope, not only to oil the rope, but also to the rope in the process of the early twisting. Grease treatment, commonly known as "strand grease" or "A2 grease".

According to the data obtained from the survey, there are some structures such as 4V*39S+5FC, 4V*48S+5FC, 35W*7 and 18*19+FC, which have a common characteristic of this kind of wire rope, which is the anti-rotation. In the process of high lift lifting, this kind of non-rotating wire rope plays an important role, and the 4V sector shares belong to the forging steel wire. When the rope and wire rope are forged, the gap between steel wire and steel wire is reduced and the structure of wire rope is more compact; 18*19S and 35W*7 need stratified twisting in the production of wire rope, and the group stranded wire is more than 200, in addition to rotation resistance, because the steel wire is fine, the steel wire has better toughness and the wire rope has more fatigue resistance.

Key Specifications/Special Features:

Technical Table
