Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife

Product Details:
Place of Origin: China
Brand Name: LKS
Certification: ISO9001
Model Number: KT
Payment & Shipping Terms:
Minimum Order Quantity: 5 Pieces
Price: $15.00 - $50.00 / Pieces
Packaging Details: Standard export package
Delivery Time: 5-15 working Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 80000 Piece/Pieces per Month

Detail Information

Type:Cable GripUsage:Insulation Protection
Material:Stainless Steel,Hot-dipped Galvanized Steel Cable GripPackaging:Plastic Bags And Carton Box
Color:Gray,whith,etcDuty:Standard Duty
Head:Single /Double HeadApplication:Cable System
High Light:

wire rope slings with hooks

,

steel wire sling

Product Description



High Tensile Galvanised Wire Rope Standard Minitye Rotate Cable Grip Sling



Rotate Cable Grip

Using multiple strands hot dip galvanized steel wire rope to weaving,used for cable head dragging,it can rotate 360 degrees,release the cable or wire rope torsion.



Safety first! Cable Connection offers a wide range of cable grips produced by LKS. Cable grips are a practical and safe solution for the installation of electricity cables, control cables, communication cables and high-voltage cables. They are also used to relieve the force on a cable or hose by distributing the weight over a larger area.

thanks to years of experience and user feedback these cable grips have significantly improved in quality over the years. Currently the cable grips are produced from high grade galvanized nineteen-fold Bowden pulling wires.

The flexible and cylindrical woven mesh adjusts to the diameter of the cable and forms a tight grip around the cable exterior without the risk of slipping. This ensures the cable can only grip tighter as more tension is put on the cable.
A very Important factor to get the desired strength from the grip is to make sure the cable diameter is within the diameter reach of the cable grip If the grips are too big they could slide of if placed under tension!
Cable Connection would gladly advise you about the size of cable grip you need. If desired we can visit your location. We are always looking for the best solution after all.



Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 0



pecifications



Rotate Cable Grip Specification

We can produce by your samples or technical drawings.

We can build the molds and fixtures.

Model

Size Range

(mm)

Mesh Length

(mm)

Total Length

(mm)

Breaking (KN) Strength (KG)
KT-18 13-18 500 580 19.6 2000
KT-25 18-25 520 620 24.5 2500
KT-30 25-34 550 680 34.3 3500
KT-40 35-48 620 780 58.8 6000
KT-55 49-60 750 980 78.4 8000
KT-70 60-75 900 1180 78.4 8000
KT-85 75-90 950 1220 88.2 9000
KT-100 90-115 1000 1320 107.8 11000
KT-120 110-135 1180 1450 117.6 12000
KT-140 130-150 1250 1620 132.3 13500

Related Products



Various Types Of Cable Pulling Grips

We can produce by your samples or technical drawings.

We can build the molds and fixtures.

Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 1

Packaging & Delivery

The Cable Grip is usually packed by the carton.

Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 2

Application



Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 3

FAQ

Q: How we get the samles?

A: For we are manufacture. If we have stock our sales can arrange it for ur part after ur confirmation. If customer requiry spec. It need 3-5 days for oem service.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but need the customer arrange the cost of freight.

Q: What is your MOQ ?

A: 1 PCS is accetable.



 Product Show



Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 4

Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 5

Heavy Duty Rotate Wire Rope Sling Hose Restraint Multiple Strength Longlife 6
