Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | LKS |
| Certification: | CCS,DNV,BV |
| Model Number: | LKS-WRS1159 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1Set |
| Price: | USD1-100 PER SET |
| Packaging Details: | Wooden Box |
| Delivery Time: | 10-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000SETS Monthly |
|
Detail Information |
|||
| Model: | T/T | Wire Rope Size: | 1/2" |
|---|---|---|---|
| Type: | Single Leg Thimbled Eyes | Construction: | 6x19 Class |
| Length (ft): | 5,,10,20,30,40,50... | Safety Factor: | 5:1 |
| Applications: | Any Industry Including Oil & Gas, Construction, Manufacturing, And Mining... | HS Code: | 73129000 |
| High Light: |
wire rope slings with hooks,steel wire sling |
||
Product Description
| Part Number | LKS-WRS1159 |
|---|---|
| Load Capacity | 5000.00 pounds |
| Color | Eye-to-Eye Flemish Loop Ends |
| Item Weight | 3.12 pounds |
| Number of Items | 1 |
| Size | 3-Foot Length |
| Brand Name | LKS |
|---|
Description:
When looking for strength and durability on that next big rigging job, look no further than our array of LKS Wire Rope Slings. A wide-variety of sizes are available whether working on a small-load lift or preparing to maneuver a massively heavy element. Our slings are there to solve your hoisting, lifting and towing problems.
LKS slings are assembled in an ISO 9001:2015 certified facility where quality, safety and efficiency are priority. Audits are conducted every year by an independent third-party to determine if a manufacturer is compliant with standards before re-registration.
The wide offering of Single Leg Wire Rope Slings will surely meet your rigging needs on the jobsite. Each eye on these slings is formed using the mechanical Flemish Eye Splice. This process allows for the most efficient use of the rope capacity with top-quality steel as the pull is directly along the centerline of the rope and eye.
Wire Rope Diameter - 1/2 Inch
Terminal Fittings - Eye-to-Eye Flemish Loop Ends
Sling Legs - 1
Sling Length - 3-Feet
Single Leg Vertical Rated Capacity - 2.5 Ton
Choker Hitch Rated Capacity - 1.9 Ton
60-Degree Basket Rated Capacity - 4.4 Ton
45-Degree Basket Rated Capacity - 3.6 Ton
30-Degree Basket Rated Capacity - 2.5 Ton
Loop Dimensions:
Safety Compliance:
The wire rope sling can be divided into three types according to the different processing methods: inserting wire rope sling, pressing wire rope sling, casting wire rope sling, and nonjoint wire rope sling. The following are the following:
1. circular or circular processing is made by inserting or pressing one end or two ends.
2. Sling with cast alloy or resin.
3. Sling made of rope clamps.
4. in the form of non-endless wire rope sling
5. according to the requirements, it can be made into single, double legs, three legs, 4legss or more legs wire rope sling.
